MB 300SE/Cp W112.021 with engine 189.985

Chosen model:

Chassis: 112.021
Engine: 189.985
Choose different model

Current unit you are viewing: 20 Engine Cooling

Pic.	Niemöller part-no.	Designation		Price/unit excl. tax.
Image number		D 20 200 D 20 200	Water pump including gasket Water pump including gasket 186 200 08 20 oder 1862000820		€550.00 €550.00
Image number		D 20 200 D 20 200	Water pump including gasket Water pump including gasket 189 200 04 20 oder 1892000420		€550.00 €550.00
Image number 110		D 20 257 D 20 257	Magnetic coupling Magnetic coupling 189 200 01 27 oder 1892000127		on request on request
Image number 112		D 20 259	Bearing pedestal 189 200 03 28 oder 1892000328		on request	Choose the suitable product variant
Image number 112	Image number 112		D 20 259	Bearing pedestal 189 200 05 28 oder 1892000528		Choose the suitable product variant	on request
Image number		D 20 261 D 20 261	Snap ring Snap ring 189 994 00 35 oder 1899940035		on request on request
Image number 113		D 20 264 D 20 264	Bearring Bearring 000 625 006 203 oder 000625006203		€7.50 €7.50
Image number 115		D 20 262	Pulley with shaft 189 200 03 21 oder 1892000321		on request	Choose the suitable product variant
Image number 115	Image number 115		D 20 262	Pulley with shaft 189 200 04 21 oder 1892000421		Choose the suitable product variant	on request
Image number 117		C 05 089 C 05 089	Seeger Ring Seeger Ring 000 471 017 000 oder 000471017000		€1.29 €1.29
Image number 118		D 20 269	O-ring 003 997 83 45 oder 0039978345		on request	Choose the suitable product variant
Image number 118	Image number 118		D 20 268	End cover 189 206 00 57 oder 1892060057		Choose the suitable product variant	on request
Image number		D 20 270 D 20 270	Retaining ring Retaining ring 000 472 004 000 oder 000472004000		on request on request
Image number 122		D 20 271 D 20 271	Fan hub Fan hub 189 200 01 26 oder 1892000126		on request on request
Image number 123		D 20 273 D 20 273	Sealing ring Sealing ring 003 997 13 46 oder 0039971346		€8.00 €8.00
Image number 124		D 20 270 D 20 270	Retaining ring Retaining ring 000 472 040 000 oder 000472040000		on request on request
Image number 125		D 20 274 D 20 274	Angular ball bearings Angular ball bearings 000 628 003 203 oder 000628003203		on request on request
Image number 126		C 05 089 C 05 089	Seeger Ring Seeger Ring 000 471 017 000 oder 000471017000		€1.29 €1.29
Image number 127		D 20 254 D 20 254	Sealing flange Sealing flange 189 205 00 80 oder 1892050080		€6.30 €6.30
Image number 128		D 20 276 D 20 276	Sealing cover Sealing cover 189 205 00 13 oder 1892050013		on request on request
Image number 129		C 01 258 C 01 258	Hex. socket screw Hex. socket screw 000 912 006 004 oder 000912006004		€0.75 €0.75
Image number 131		C 07 425 C 07 425	Hex. nut Hex. nut 000 934 006 006 oder 000934006006		€0.40 €0.40
Image number 135		D 20 278	Retaining plate for belt tensioner 112 200 00 40 oder 1122000040		€20.50	Choose the suitable product variant
Image number 135	Image number 135		D 20 279	Retaining plate for belt tensioner 189 206 02 40 oder 1892060240		Choose the suitable product variant	on request
Image number 136		D 13 070 D 13 070	Sealing ring Sealing ring 000 997 23 41 oder 0009972341		€1.40 €1.40
Image number 137		D 20 280 D 20 280	Stud/R.sp.+L.b.an Z.-K.gh. Stud/R.sp.+L.b.an Z.-K.gh. 189 206 00 70 oder 1892060070		on request on request
Image number 138		D 20 281 D 20 281	Bolt/R.sp.+L.b.an Cyl.kurb.geh. Bolt/R.sp.+L.b.an Cyl.kurb.geh. 189 206 00 74 oder 1892060074		on request on request
Image number 139		D 29 082 D 29 082	Disc, push rod on clutch pedal Disc, push rod on clutch pedal 000 125 008 407 oder 000125008407		on request on request
Image number 140		D 20 282 D 20 282	Hexagon nut/R.sp.+L.b.an Z.K.gh Hexagon nut/R.sp.+L.b.an Z.K.gh 189 990 04 51 oder 1899900451		on request on request
Image number 141		G 75 029 C 32 027	Hex nut Hex. nut M 8 000 934 008 008 oder 000934008008		on request €0.54
	C 32 027	Replacement: Hex. nut M 8		€0.54
Image number 145		D 20 283 D 20 283	Holder/R.sp.+L.b.an Z.kgh. Holder/R.sp.+L.b.an Z.kgh. 189 200 11 40 oder 1892001140		on request on request
Image number 146		A 54 225 A 54 225	Rubber grommet Rubber grommet 000 997 22 81 oder 0009972281		€1.40 €1.40
Image number 147		A 46 113 A 46 113	Washer for steering lock on carrier Washer for steering lock on carrier 312 990 19 40 oder 3129901940		€4.00 €4.00
Image number 149		G 75 029 C 32 027	Hex nut Hex. nut M 8 000 934 008 008 oder 000934008008		on request €0.54
	C 32 027	Replacement: Hex. nut M 8		€0.54
Image number 150		D 20 285	V-belts 000 997 54 92 oder 0009975492		€31.10	Choose the suitable product variant
Image number 150	Image number 150		D 20 286	Fan belt 13x975 000 997 51 92 oder 0009975192		Choose the suitable product variant	€27.88
Image number 155		D 20 286a D 20 286a	Blower Blower 188 205 00 06 oder 1882050006		on request on request
Image number 156		G 35 010 G 35 010	Hexagon head screw M8x22 DIN 933-8G Hexagon head screw M8x22 DIN 933-8G 000 933 008 114 oder 000933008114		€2.20 €2.20
Image number 157		B 03 018 B 03 018	Spring washer Spring washer 000 137 008 202 oder 000137008202		€0.30 €0.30
Image number		C 20 146 C 20 146	Engine plate N 202 MN 5 Engine plate N 202 MN 5 900 202 000 700 oder 900202000700		on request on request
Image number		A 58 015 A 58 015	Nail Nail 001 476 003 002 oder 001476003002		€1.00 €1.00

Please note that the product names may be an automatic translation for which no guarantee can be given.

in stock
low stock level
currently not in stock, but available for order
no longer available

D 20 200 €550.00

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 257

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 259

D 20 261

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 264 €7.50

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666
NO LONGER AVAILABLE

D 20 262

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

C 05 089 €1.29

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 269

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 268

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 270

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 271

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 273 €8.00

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 270

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 274

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

C 05 089 €1.29

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 254 €6.30

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 276

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

C 01 258 €0.75

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

C 07 425 €0.40

10/20 UP TO ENGINE 000166 12/22 UP TO ENGINE 000665

D 20 278 €20.50

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 279

D 13 070 €1.40

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 280

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 281

D 29 082

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 282

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 283

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

A 54 225 €1.40

A 46 113 €4.00

10/20 UP TO ENGINE 000166 12/22 UP TO ENGINE 000665

D 20 285 €31.10

10/20 FROM ENGINE 000167 12/22 FROM ENGINE 000666

D 20 286 €27.88

D 20 286a

G 35 010 €2.20

B 03 018 €0.30

C 20 146

A 58 015 €1.00
