MB 280SL W107.042 with engine 110.990

Chosen model:

Chassis: 107.042
Engine: 110.990
Choose different model

Current unit you are viewing: 29 Pedal Assembly

Pic.	Niemöller part-no.	Designation		Price/unit excl. tax.
Image number 20		F 29 016	Brake pedal 107 290 20 18 oder 1072902018		on request	Choose the suitable product variant
	Image number 20		F 29 018	Brake pedal 107 290 22 18 oder 1072902218			on request
	Image number 20		F 29 020	Brake pedal R.L. 116 290 04 18 oder 1162900418			on request
	Image number 20		F 29 022	Brake pedal R.L. 107 290 24 18 oder 1072902418			on request
Image number 23		D 29 041 D 29 041	Bushing Bushing 124 292 00 50 oder 1242920050		€1.54 €1.54
Image number 26		D 29 053	Bushing 110 292 01 50 oder 1102920150		€3.87	Choose the suitable product variant
Image number 26	Image number 26		F 29 023	Bushing 126 292 00 50 oder 1262920050		Choose the suitable product variant	€2.25
Image number 35		D 29 039a D 29 039a	Rubber pad for clutch / brake pedal Rubber pad for clutch / brake pedal 107 291 01 82 oder 1072910182		€3.00 €3.00
Image number 38		F 29 024 F 29 024	Pedal cover Pedal cover 123 291 00 82 oder 1232910082		€5.50 €5.50
Image number 41		F 29 009	Clutch pedal 107 290 22 16 oder 1072902216		on request	Choose the suitable product variant
Image number 41	Image number 41		F 29 012	Clutch pedal R.L. 107 290 24 16 oder 1072902416		Choose the suitable product variant	on request
Image number 44		D 29 041 D 29 041	Bushing Bushing 124 292 00 50 oder 1242920050		€1.54 €1.54
Image number 47		F 29 043	Safety catch 000 994 11 51 oder 0009941151		€3.33	Choose the suitable product variant
	Image number 47		F 29 043	Safety catch 000 994 11 51 oder 0009941151			€3.33
	Image number 47		A 42 029	Seegering ring for brake shoe a. Aufh.bolz. 007 994 20 41 oder 0079942041			€1.60
	Image number 47		A 42 029	Seegering ring for brake shoe a. Aufh.bolz. 007 994 20 41 oder 0079942041			€1.60
Image number 50		F 29 047	Washer 115 291 00 76 oder 1152910076		€1.64	Choose the suitable product variant
Image number 50	Image number 50		F 29 047	Washer 115 291 00 76 oder 1152910076		Choose the suitable product variant	€1.64
Image number 53		D 54 798 D 54 798	Brake light switch Brake light switch 000 545 35 09 oder 0005453509		€28.00 €28.00
Image number 59		D 54 802 D 54 802	Nut, brake light switch on pedal system Nut, brake light switch on pedal system 000 990 92 51 oder 0009909251		€42.49 €42.49
Image number 62		C 29 114 C 29 114	Spring Spring 107 993 04 10 oder 1079930410		€46.31 €46.31
Image number 65		F 29 045 F 29 045	Snubber Snubber 107 291 00 86 oder 1072910086		€4.17 €4.17
Image number 71		F 29 049 F 29 049	Holder, over-centre spring Holder, over-centre spring 115 291 05 40 oder 1152910540		on request on request
Image number 77		G 30 102 G 30 102	Spring washer Spring washer 000 137 006 204 oder 000137006204		€0.72 €0.72
Image number 80		G 42 104 G 42 104	Nut, hydraulic unit on holder Nut, hydraulic unit on holder 304 032 006 008 oder 304032006008		€14.34 €14.34
Image number 83		D 29 067	Pressure rod 115 290 13 39 oder 1152901339		on request	Choose the suitable product variant
Image number 83	Image number 83		F 29 052	Pressure rod 107 290 01 39 oder 1072900139		Choose the suitable product variant	€6.04
Image number 86		D 29 070 D 29 070	Bearing race Bearing race 110 291 07 50 oder 1102910750		€17.54 €17.54
Image number 89		F 29 054 F 29 054	Spring Spring 107 993 05 01 oder 1079930501		€25.00 €25.00
Image number 92		D 29 073 D 29 073	Spring retainer Spring retainer 111 291 04 91 oder 1112910491		€5.80 €5.80
Image number 98		D 29 072 D 29 072	Locking nut Locking nut 007 967 010 001 oder 007967010001		on request on request
Image number 104		C 05 033 C 05 033	Lock washer for threaded bolt Lock washer for threaded bolt 006 799 006 003 oder 006799006003		€0.84 €0.84
Image number 110		D 20 079 D 20 079	Hex screw 6x22 Hex screw 6x22 000 933 006 123 oder 000933006123		€3.59 €3.59
Image number 113		G 42 103 G 42 103	Washer, hydraulic unit on holder Washer, hydraulic unit on holder 009 021 006 208 oder 009021006208		€1.12 €1.12
Image number 116		G 30 102 G 30 102	Spring washer Spring washer 000 137 006 204 oder 000137006204		€0.72 €0.72
Image number 119		G 42 104 G 42 104	Nut, hydraulic unit on holder Nut, hydraulic unit on holder 304 032 006 008 oder 304032006008		€14.34 €14.34
Image number 122		F 29 057 F 29 057	Gasket Gasket 115 431 01 80 oder 1154310180		€6.04 €6.04

Please note that the product names may be an automatic translation for which no guarantee can be given.

in stock
low stock level
currently not in stock, but available for order
no longer available

Left-hand-drive;

As of ident. no.
022 007568
023 013674
024 028398
026 001238
042 006762
043 014821
044 058449

F 29 016

Left-hand-drive;

As of ident. no.
022 007568
023 013674
024 028398
026 001238
042 006762
043 014821
044 058449

F 29 018

Right-hand-drive;

As of ident. no.
022 007568
023 013674
024 028398
026 001238
042 006762
043 014821
044 058449

F 29 020

Right-hand-drive;

As of ident. no.
022 007568
023 013674
024 028398
026 001238
042 006762
043 014821
044 058449

F 29 022

D 29 041 €1.54

Up to ident. no.:
022 007567
023 013673
024 028397
026 001237
042 006761
043 014820
044 058448

D 29 053 €3.87

As of ident. no.
022 007568
023 013674
024 028398
026 001238
042 006762
043 014821
044 058449

F 29 023 €2.25

D 29 039a €3.00

F 29 024 €5.50

Left-hand-drive;

As of ident. no.
022 006064
023 012955
042 005052
043 013990

F 29 009

Right-hand-drive;

As of ident. no.
022 006064
023 012955
042 005052
043 013990

F 29 012

D 29 041 €1.54

Up to ident. no.:
022 006587
023 013210
024 025987
026 000725
042 005629
043 014263
044 054082

F 29 043 €3.33

As of ident. no.
022 006588
023 013211
024 025988
026 000726
042 005630
043 014264
044 054083
As of ident. no.
022 006588
023 013211
024 025988
026 000726
042 005630
043 014264
044 054083

A 42 029 €1.60

F 29 047 €1.64

D 54 798 €28.00

D 54 802 €42.49

C 29 114 €46.31

F 29 045 €4.17

F 29 049

G 30 102 €0.72

G 42 104 €14.34

Up to ident. no.:
022 006063
023 012954
042 005051
043 013989

D 29 067

As of ident. no.
022 006064
023 012955
042 005052
043 013990

F 29 052 €6.04

Up to ident. no.:
022 006063
023 012954
042 005051
043 013989

D 29 070 €17.54

F 29 054 €25.00

D 29 073 €5.80

NO LONGER AVAILABLE

D 29 072

C 05 033 €0.84

As of ident. no.
043 10/50 003627
043 12/52 002884
043 20/60 004314
043 22/62 002359

D 20 079 €3.59

As of ident. no.
043 10/50 003627
043 12/52 002884
043 20/60 004314
043 22/62 002359

G 42 103 €1.12

As of ident. no.
043 10/50 003627
043 12/52 002884
043 20/60 004314
043 22/62 002359

G 30 102 €0.72

As of ident. no.
043 10/50 003627
043 12/52 002884
043 20/60 004314
043 22/62 002359

G 42 104 €14.34

F 29 057 €6.04
