280SE Mercedes-Benz w116.024

Chosen model:

Chassis: 116.024
Engine: 110.983, 985
Choose different model

Current unit you are viewing: 46 Steering

Pic.	Niemöller part-no.	Designation		Price/unit excl. tax.
Image number 1		F 46 110	Steering 116 460 08 01 oder 1164600801		on request	Choose the suitable product variant
Image number 1	Image number 1		F 46 112	Steering right hand drive 116 460 09 01 oder 1164600901		Choose the suitable product variant	€623.48
Image number 10		F 46 118 F 46 118	Sealing ring Sealing ring 009 997 44 45 oder 0099974445		€3.87 €3.87
Image number 12		F 46 119 F 46 119	Safety catch Safety catch 001 994 84 41 oder 0019948441		€3.87 €3.87
Image number 14		F 46 120 F 46 120	Sealing ring Sealing ring 009 997 48 45 oder 0099974845		€6.58 €6.58
Image number 18		F 46 121 F 46 121	Threaded bush Threaded bush 107 460 02 86 oder 1074600286		€95.00 €95.00
Image number 20		F 46 122 F 46 122	Washer Washer 001 990 55 40 oder 0019905540		€4.71 €4.71
Image number 22		F 46 123 F 46 123	Needle roller bearings Needle roller bearings 004 981 10 10 oder 0049811010		on request on request
Image number 24		G 46 008 G 46 008	Sealing ring below Sealing ring below 011 997 67 46 oder 0119976746		€20.76 €20.76
Image number 27		F 46 125 F 46 125	Safety catch Safety catch 001 994 25 41 oder 0019942541		€2.91 €2.91
Image number 29		F 46 126 F 46 126	Sealing ring Sealing ring 009 997 46 45 oder 0099974645		€4.30 €4.30
Image number 32		F 46 127 F 46 127	Sealing ring Sealing ring 009 997 43 45 oder 0099974345		€14.41 €14.41
Image number 34		F 46 128 F 46 128	Sealing ring Sealing ring 107 466 00 60 oder 1074660060		€5.80 €5.80
Image number 36		F 46 129 F 46 129	Roller bearings Roller bearings 000 981 48 18 oder 0009814818		€10.02 €10.02
Image number 38		F 46 130 F 46 130	Spadices Spadices 107 466 05 83 oder 1074660583		on request on request
Image number 44		F 46 132 F 46 132	Angular contact bearing Angular contact bearing 000 981 54 27 oder 0009815427		€72.45 €72.45
Image number 46		F 46 133 F 46 133	Roller bearings Roller bearings 000 981 49 18 oder 0009814918		€9.98 €9.98
Image number 48		F 46 122 F 46 122	Washer Washer 001 990 55 40 oder 0019905540		€4.71 €4.71
Image number 50		F 46 134 F 46 134	Sealing ring Sealing ring 009 997 45 45 oder 0099974545		€2.25 €2.25
Image number 52		F 46 135 F 46 135	Sealing ring Sealing ring 107 466 01 60 oder 1074660160		€8.62 €8.62
Image number 57		F 46 136 F 46 136	Sealing ring Sealing ring 107 466 02 60 oder 1074660260		€8.61 €8.61
Image number 59		F 46 137 F 46 137	Sealing ring Sealing ring 009 997 42 45 oder 0099974245		€2.25 €2.25
Image number 62		F 46 138	Steering shaft 107 460 02 11 oder 1074600211		on request	Choose the suitable product variant
Image number 62	Image number 62		F 46 139	Steering shaft, set of parts 123 460 06 11 oder 1234600611		Choose the suitable product variant	on request
Image number 73		G 46 007 G 46 007	Fuse Fuse 004 994 92 41 oder 0049949241		€3.30 €3.30
Image number 75		F 46 152 F 46 152	Thrust ring Thrust ring 107 462 07 62 oder 1074620762		on request on request
Image number 77		D 08 875 D 08 875	Retaining ring Retaining ring 000 471 012 001 oder 000471012001		€2.31 €2.31
Image number 82		F 46 153	Top 107 460 06 15 oder 1074600615		on request	Choose the suitable product variant
	Image number 82		F 46 154	Top 114 460 00 15 oder 1144600015			€134.15
	Image number 82		F 46 155	Cover right hand drive 107 460 07 15 oder 1074600715			on request
	Image number 82		F 46 156	Cover R.L. 114 460 01 15 oder 1144600115			on request
Image number 86		F 46 157 F 46 157	Sealing ring top Sealing ring top 019 997 50 47 oder 0199975047		€8.10 €8.10
Image number 88		E 46 025 E 46 025	Retaining ring Retaining ring 000 994 98 41 oder 0009949841		€3.73 €3.73
Image number 92		F 46 159 F 46 159	Sealing ring Sealing ring 009 997 47 45 oder 0099974745		€5.04 €5.04
Image number 97		G 47 042 G 47 042	Sealing ring a 12X17Cu Sealing ring a 12X17Cu 007 603 012 110 oder 007603012110		€0.70 €0.70
Image number 97D		F 46 137 F 46 137	Sealing ring Sealing ring 009 997 42 45 oder 0099974245		€2.25 €2.25
Image number 98		F 27 075 F 27 075	Screw plug Screw plug 115 997 00 30 oder 1159970030		€3.68 €3.68
Image number 102		G 46 004 G 46 004	Sealing ring A 8x11,5Cu Sealing ring A 8x11,5Cu 007 603 008 109 oder 007603008109		€1.52 €1.52
Image number 104		C 01 100 C 01 100	Screw fitting Screw fitting 636 090 00 69 oder 6360900069		€6.09 €6.09
Image number 106		A 42 098 A 42 098	Sealing ring 16x20 Cu Sealing ring 16x20 Cu 007 603 016 401 oder 007603016401		€0.50 €0.50
Image number 108		D 07 331 D 08 028	Screw neck Fitting 915 013 006 002 oder 915013006002		on request €9.00
	D 08 028	Replacement: Fitting		€9.00
Image number 110		G 46 006 A 09 017	Sealing ring Sealing ring A 12x16 Cu - DIN 7603 007 603 012 405 oder 007603012405		on request €0.60
	A 09 017	Replacement: Sealing ring A 12x16 Cu - DIN 7603		€0.60
Image number 112		F 46 161 F 46 161	Screw Screw 114 990 00 01 oder 1149900001		on request on request
Image number 113		F 46 162 F 46 162	Nut, steering column lever Nut, steering column lever 001 990 54 51 oder 0019905451		€7.66 €7.66
Image number 115		F 46 163 F 46 163	Repair kit Repair kit 107 460 00 37 oder 1074600037		on request on request
Image number 118		F 46 164 F 46 164	Repair kit (gasket set) Repair kit (gasket set) 107 586 01 46 oder 1075860146		€22.80 €22.80
Image number 121		F 46 169	Control stalk 116 463 10 01 oder 1164631001		on request	Choose the suitable product variant
Image number 121	Image number 121		F 46 173	Steering column lever R.L. 116 463 11 01 oder 1164631101		Choose the suitable product variant	on request
Image number 130		F 46 179 F 46 179	Screw 110mm long Screw 110mm long 116 990 18 01 oder 1169901801		€9.66 €9.66
Image number 134		D 46 054 D 46 054	Steering coupling Steering coupling 115 460 02 10 oder 1154600210		€123.00 €123.00
Image number 135		D 46 062 D 46 062	Washer Washer 124 990 41 40 oder 1249904140		€0.78 €0.78
Image number 136		D 46 059 D 46 059	Bushing, steering coupling Bushing, steering coupling 111 462 01 65 oder 1114620165		€6.03 €6.03
Image number 139		F 27 116 F 27 116	Plastic washer Plastic washer 111 990 30 40 oder 1119903040		on request on request
Image number 140		D 46 058 D 46 058	Lock clip Lock clip 912 002 010 001 oder 912002010001		€2.06 €2.06
Image number 144		G 32 012 G 32 012	Spring washer, shock absorber on lower wishbone Spring washer, shock absorber on lower wishbone 912 006 008 000 oder 912006008000		€0.69 €0.69
Image number 147		D 46 063 G 46 062	Fillister head screw Screw 111 990 04 20 oder 1119900420		on request €2.78
	G 46 062	Replacement: Screw		€2.78
Image number 249		F 46 209 F 46 209	Drag link, center Drag link, center 116 460 06 05 oder 1164600605		€36.00 €36.00
Image number 249B		F 46 090 C 33 132	Boot Cover 000 463 04 96 oder 0004630496		on request €17.09
	C 33 132	Replacement: Cover		€17.09
Image number 249D		F 46 089 C 33 132	Washer Cover 000 463 00 97 oder 0004630097		on request €17.09
	C 33 132	Replacement: Cover		€17.09
Image number 250		D 33 134 D 33 134	Boot rep kit Boot rep kit 000 330 04 85 oder 0003300485		€9.15 €9.15
Image number 250A		C 46 209 C 33 134	Castle nut for handlebar Castel nut M10x1		on request €2.50
	C 33 134	Replacement: Castel nut M10x1		€2.50
Image number		G 46 114 G 46 114	Cotter pin Cotter pin 000 094 002 077 oder 000094002077		€2.25 €2.25
Image number		F 46 214 F 46 214	Rivet Rivet 910 003 004 131 oder 910003004131		on request on request
Image number 254		F 46 216	Intermediate lever 116 463 09 10 oder 1164630910		€205.00	Choose the suitable product variant
Image number 254	Image number 254		F 46 220	Intermediate lever 116 463 10 10 oder 1164631010		Choose the suitable product variant	on request
Image number 256		G 46 105 G 46 105	Hex nut Hex nut 910 113 016 002 oder 910113016002		€5.88 €5.88
Image number 257		G 46 102 G 46 102	Screw Screw 000 960 016 287 oder 000960016287		on request on request
Image number 258		G 46 105 G 46 105	Hex nut Hex nut 910 113 016 002 oder 910113016002		€5.88 €5.88
Image number 260		D 46 412 D 46 412	Cap Cap 111 463 10 56 oder 1114631056		€7.75 €7.75
Image number 262		D 46 414 D 46 414	Repair kit, intermidiate lever Repair kit, intermidiate lever 123 460 00 50 oder 1234600050		€35.00 €35.00
Image number		F 46 094 F 46 094	Distance washer Distance washer 115 463 01 52 oder 1154630152		€8.58 €8.58
Image number 265		D 46 428 D 46 428	Steering shock absorber Steering shock absorber 000 463 35 32 oder 0004633532		€36.68 €36.68
Image number 267		B 22 006 B 22 006	Spring washer Spring washer 000 137 010 201 oder 000137010201		€0.84 €0.84
Image number 269		G 46 117 A 46 154	Screw DIN 960 10x1x40 Hexagon head screw 10x1x40 DIN 960 000 960 010 026 oder 000960010026		on request €26.00
	A 46 154	Replacement: Hexagon head screw 10x1x40 DIN 960		€26.00
Image number 271		G 46 118 G 46 118	Hex nut Hex nut 910 113 010 002 oder 910113010002		€3.31 €3.31

Please note that the product names may be an automatic translation for which no guarantee can be given.

in stock
low stock level
currently not in stock, but available for order
no longer available

Left-hand-drive;

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 110

Right-hand-drive;

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 112 €623.48

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 118 €3.87

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 119 €3.87

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 120 €6.58

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 121 €95.00

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 122 €4.71

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 123

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

G 46 008 €20.76

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 125 €2.91

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 126 €4.30

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 127 €14.41

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 128 €5.80

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 129 €10.02

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 130

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 132 €72.45

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 133 €9.98

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 122 €4.71

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 134 €2.25

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 135 €8.62

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 136 €8.61

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 137 €2.25

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 138

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 139

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

G 46 007 €3.30

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 152

UP TO CHASSIS:
020

D 08 875 €2.31

Left-hand-drive;

UP TO CHASSIS:
020 000061
024 000068
028 000627

F 46 153

Left-hand-drive;

FROM CHASSIS:
020 000062
024 000069
028 000628

F 46 154 €134.15

Right-hand-drive;

UP TO CHASSIS:
020 000061
024 000068
028 000627

F 46 155

Right-hand-drive;

FROM CHASSIS:
020 000062
024 000069
028 000628

F 46 156

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 157 €8.10

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

E 46 025 €3.73

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 159 €5.04

UP TO CHASSIS:
020

G 47 042 €0.70

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 137 €2.25

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 27 075 €3.68

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

G 46 004 €1.52

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

C 01 100 €6.09

UP TO CHASSIS:
020

A 42 098 €0.50

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 161

F 46 162 €7.66

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 163

UP TO CHASSIS:
020 046749
024,025 046779
028,029 028143
032,033 040254
FROM CHASSIS,SEE SPARE PARTS LIST 765.7

F 46 164 €22.80

Left-hand-drive

F 46 169

Right-hand-drive

F 46 173

FOR REPAIRS ON SIDE MEMBER ONLY

F 46 179 €9.66

D 46 054 €123.00

UP TO CHASSIS:
020 015900
024,025 017956
028,029 016512
032,033 015650

D 46 062 €0.78

UP TO CHASSIS:
020 015900
024,025 017956
028,029 016512
032,033 015650

D 46 059 €6.03

UP TO CHASSIS:
020

F 27 116

UP TO CHASSIS:
020

D 46 058 €2.06

G 32 012 €0.69

F 46 209 €36.00

UP TO CHASSIS:
020 108673
024,025 124850
028,029 048820
032,033 085187
036 004972

UP TO CHASSIS:
020 108673
024,025 124850
028,029 048820
032,033 085187
036 004972

D 33 134 €9.15

FROM CHASSIS:
020 108674
024,025 124851
028,029 048821
032,033 085188
036 004973

G 46 114 €2.25

F 46 214

Left-hand-drive

F 46 216 €205.00

Right-hand-drive

F 46 220

G 46 105 €5.88

G 46 102

G 46 105 €5.88

D 46 412 €7.75

D 46 414 €35.00

SUBSEQUENT INSTALLATION

F 46 094 €8.58

D 46 428 €36.68

B 22 006 €0.84

G 46 118 €3.31

in stock
low stock level
currently not in stock, but available for order
no longer available

F 46 110

F 46 112 €623.48

F 46 118 €3.87

F 46 119 €3.87

F 46 120 €6.58

F 46 121 €95.00

F 46 122 €4.71

F 46 123

G 46 008 €20.76

F 46 125 €2.91

F 46 126 €4.30

F 46 127 €14.41

F 46 128 €5.80

F 46 129 €10.02

F 46 130

F 46 132 €72.45

F 46 133 €9.98

F 46 122 €4.71

F 46 134 €2.25

F 46 135 €8.62

F 46 136 €8.61

F 46 137 €2.25

F 46 138

F 46 139

G 46 007 €3.30

F 46 152

D 08 875 €2.31

F 46 153

F 46 154 €134.15

F 46 155

F 46 156

F 46 157 €8.10

E 46 025 €3.73

F 46 159 €5.04

G 47 042 €0.70

F 46 137 €2.25

F 27 075 €3.68

G 46 004 €1.52

C 01 100 €6.09

A 42 098 €0.50

F 46 161

F 46 162 €7.66

F 46 163

F 46 164 €22.80

F 46 169

F 46 173

F 46 179 €9.66

D 46 054 €123.00

D 46 062 €0.78

D 46 059 €6.03

F 27 116

D 46 058 €2.06

G 32 012 €0.69

F 46 209 €36.00

D 33 134 €9.15

G 46 114 €2.25

F 46 214

F 46 216 €205.00

F 46 220

G 46 105 €5.88

G 46 102

G 46 105 €5.88

D 46 412 €7.75

D 46 414 €35.00

F 46 094 €8.58

D 46 428 €36.68

B 22 006 €0.84

G 46 118 €3.31

in stock
low stock level
currently not in stock, but available for order
no longer available
