MB 220SECp W128.037 engine 127.983

Chosen model:

Chassis: 128.037
Engine: 127.983
Choose different model

Current unit you are viewing: 29 Pedal Assembly

Pic.	Niemöller part-no.	Designation		Price/unit excl. tax.
Image number 1		C 29 001 C 29 001	Brake foot lever with bushing Brake foot lever with bushing 180 290 01 18 oder 1802900118		on request on request
Image number 2		C 29 003 C 29 003	Bushing for brake pedal Bushing for brake pedal 120 292 05 50 oder 1202920550		€37.00 €37.00
Image number 4		C 29 007	Washer 1,5mm 120 990 28 40 oder 1209902840		on request	Choose the suitable product variant
Image number 4	Image number 4		C 29 007	Washer 1,5mm 120 990 28 40 oder 1209902840		Choose the suitable product variant	on request
Image number		C 29 009 C 29 009	Washer 0,58mm for clutch pedal Washer 0,58mm for clutch pedal 120 990 38 40 oder 1209903840		€7.59 €7.59
Image number 5		C 29 008 C 29 008	Disc 3,0mm thick for brake lever Disc 3,0mm thick for brake lever 120 990 42 40 oder 1209904240		€7.00 €7.00
Image number		C 29 009 C 29 009	Washer 0,58mm for clutch pedal Washer 0,58mm for clutch pedal 120 990 38 40 oder 1209903840		€7.59 €7.59
Image number		C 29 009a C 29 009a	Washer 0.75mm thick on clutch pedal Washer 0.75mm thick on clutch pedal 120 990 39 40 oder 1209903940		€7.59 €7.59
Image number		C 29 010 C 29 010	Washer 0,88mm for brake pedal Washer 0,88mm for brake pedal 120 990 40 40 oder 1209904040		€7.59 €7.59
Image number		C 29 011 C 29 011	Washer 1,00mm for brake pedal Washer 1,00mm for brake pedal 120 990 41 40 oder 1209904140		€7.59 €7.59
Image number 6		C 29 014 C 29 014	Spacer sleeve for brake pedal Spacer sleeve for brake pedal 180 292 02 53 oder 1802920253		on request on request
Image number 10		C 29 114 C 29 114	Spring Spring 180 993 10 10 oder 1809931010		€46.31 €46.31
Image number 11		C 29 022 C 29 022	Clutch foot lever with hub and bushing Clutch foot lever with hub and bushing 120 290 25 16 oder 1202902516		on request on request
Image number 13		C 29 003 C 29 003	Bushing for brake pedal Bushing for brake pedal 120 292 05 50 oder 1202920550		€37.00 €37.00
Image number 14		C 29 032 C 29 032	Shaft for clutch operation Shaft for clutch operation 120 293 05 06 oder 1202930506		€279.69 €279.69
Image number 15		C 29 036 C 29 036	Clutch foot lever shaft R.L. Clutch foot lever shaft R.L. 180 290 01 30 oder 1802900130		on request on request
Image number 16		C 29 037 C 29 037	Silent block Silent block 120 988 00 10 oder 1209880010		€11.00 €11.00
Image number 17		C 29 007 C 29 007	Washer 1,5mm Washer 1,5mm 120 990 28 40 oder 1209902840		on request on request
Image number 20		C 29 042	Mounting bracket 120 290 00 33 oder 1202900033		€68.00	Choose the suitable product variant
Image number 20	Image number 20		C 29 046	Holder for coupling housing R.L. 180 290 00 33 oder 1802900033		Choose the suitable product variant	on request
Image number 21		C 29 047 C 29 047	Shim 2mm Shim 2mm 120 293 02 88 oder 1202930288		€6.04 €6.04
Image number 22		C 29 048 C 29 048	Shim for mounting bracket clutch housing Shim for mounting bracket clutch housing 120 293 03 88 oder 1202930388		€10.89 €10.89
Image number 25		C 29 052	Pivoting support 180 290 04 21 oder 1802900421		on request	Choose the suitable product variant
Image number 25	Image number 25		C 29 056	Swivel support R.L. 180 290 05 21 oder 1802900521		Choose the suitable product variant	on request
Image number 27		C 29 058 C 29 058	Supporting plate Supporting plate 120 293 01 43 oder 1202930143		€20.13 €20.13
Image number 29		C 29 058a C 29 058a	Hex. nut M6 for S.S.St.an H. Hex. nut M6 for S.S.St.an H. 000 990 54 51 oder 0009905451		on request on request
Image number 30		C 29 059 C 29 059	Flange with silent block Flange with silent block 120 290 03 46 oder 1202900346		€283.80 €283.80
Image number 31		C 29 037 C 29 037	Silent block Silent block 120 988 00 10 oder 1209880010		€11.00 €11.00
Image number 35		C 29 062 C 29 062	Bearing body for brake pedal Bearing body for brake pedal 120 292 02 04 oder 1202920204		€100.00 €100.00
Image number 36		C 29 119 C 29 119	Lightweight sleeve Lightweight sleeve 120 991 03 41 oder 1209910341		on request on request
Image number 37		C 29 063 C 29 063	Lever with bolt Lever with bolt 120 290 07 34 oder 1202900734		€366.30 €366.30
Image number 43		C 29 069	Spacer ring 120 291 00 51 oder 1202910051		€9.00	Choose the suitable product variant
Image number 43	Image number 43		C 29 069a	Washer 10x16x1 000 988 010 016 oder 000988010016		Choose the suitable product variant	€1.30
Image number 45		C 29 070 C 29 070	Needle cage Needle cage 000 981 18 10 oder 0009811810		€3.49 €3.49
Image number 46		C 29 072 C 29 072	Ball Ball 186 991 00 29 oder 1869910029		€37.00 €37.00
Image number 47		C 29 073 C 29 073	Spring clip Spring clip 121 993 00 26 oder 1219930026		€18.81 €18.81
Image number 48		C 29 075 C 29 075	Rubber boot Rubber boot 120 291 03 88 oder 1202910388		€7.35 €7.35
Image number 49		C 29 076 C 29 076	Rubber cap Rubber cap 120 291 02 88 oder 1202910288		€10.50 €10.50
Image number 50		C 29 021a C 29 021a	Bracket for brake foot lever Bracket for brake foot lever 120 290 11 23 oder 1202901123		on request on request
Image number 51		C 29 004 C 29 004	Rubber cover Rubber cover 319 292 00 82 oder 3192920082		€3.00 €3.00
Image number 52		C 29 079 C 29 079	Bracket for clutch foot lever Bracket for clutch foot lever 120 290 13 22 oder 1202901322		on request on request
Image number 54		A 22 022	Washer 1 mm thick 136 224 01 66 oder 1362240166		€9.06	Choose the suitable product variant
Image number 54	Image number 54		A 22 022	Washer 1 mm thick 136 224 01 66 oder 1362240166		Choose the suitable product variant	€9.06
Image number 55		C 29 082	Seal washer 120 291 03 97 oder 1202910397		€4.20	Choose the suitable product variant
Image number 55	Image number 55		C 29 082	Seal washer 120 291 03 97 oder 1202910397		Choose the suitable product variant	€4.20
Image number 57		A 29 028	Sealing washer in pedal base, rubber 136 290 00 67 oder 1362900067		€15.23	Choose the suitable product variant
Image number 57	Image number 57		A 29 028	Sealing washer in pedal base, rubber 136 290 00 67 oder 1362900067		Choose the suitable product variant	€15.23
Image number		B 29 023 B 29 023	Rubber washer sealing. clutch shaving Rubber washer sealing. clutch shaving 000 987 32 41 oder 0009873241		on request on request
Image number 60		C 29 088	Pull rod 121 290 09 39 oder 1212900939		€280.50	Choose the suitable product variant
Image number 60	Image number 60		C 29 089	Coupling rod for clutch actuation R.L 180 290 04 39 oder 1802900439		Choose the suitable product variant	on request
Image number 61		C 29 094 C 29 094	Silent block 24x10 L = 23mm Silent block 24x10 L = 23mm 186 988 00 10 oder 1869880010		€23.00 €23.00
Image number 62		C 29 099 C 29 099	Shackle for clutch adjustmment Shackle for clutch adjustmment 120 293 02 32 oder 1202930232		€158.51 €158.51
Image number 64		C 29 095 C 29 095	Threaded pin Threaded pin 180 293 00 76 oder 1802930076		€30.47 €30.47
Image number 69		C 29 102 C 29 102	Bracket for release spring Bracket for release spring 121 293 08 40 oder 1212930840		€11.09 €11.09
Image number 70		C 29 106 C 29 106	Spring Spring 121 993 02 10 oder 1219930210		€12.00 €12.00
Image number 71		C 29 116 C 29 116	Bottom fender 220a/S/SE Bottom fender 220a/S/SE 180 524 02 33 oder 1805240233		on request on request
Image number		C 29 117 G 88 123	Washer f. bottom fender Washer 5.3 DIN 9021 000 984 11 55 oder 0009841155		on request €0.99
	G 88 123	Replacement: Washer 5.3 DIN 9021		€0.99

Please note that the product names may be an automatic translation for which no guarantee can be given.

in stock
low stock level
currently not in stock, but available for order
no longer available

C 29 001

C 29 003 €37.00

Right-hand-drive

C 29 007

Left-hand-drive

C 29 009 €7.59

Left-hand-drive

C 29 008 €7.00

Left-hand-drive

C 29 009 €7.59

Left-hand-drive

C 29 009a €7.59

Left-hand-drive

C 29 010 €7.59

Left-hand-drive

C 29 011 €7.59

Left-hand-drive

C 29 014

C 29 114 €46.31

Left-hand-drive

C 29 022

C 29 003 €37.00

Left-hand-drive

C 29 032 €279.69

Right-hand-drive

C 29 036

Right-hand-drive

C 29 037 €11.00

Right-hand-drive

C 29 007

Left-hand-drive

C 29 042 €68.00

Right-hand-drive

C 29 046

C 29 047 €6.04

C 29 048 €10.89

Left-hand-drive

C 29 052

Right-hand-drive

C 29 056

C 29 058 €20.13

C 29 058a

Left-hand-drive

C 29 059 €283.80

Left-hand-drive

C 29 037 €11.00

Right-hand-drive

C 29 062 €100.00

Right-hand-drive

C 29 119

For the 190SL:
up to chassis number 5500107
and from chassis number 5501613.
In between see C 29 064

C 29 063 €366.30

C 29 069 €9.00

C 29 069a €1.30

C 29 070 €3.49

C 29 072 €37.00

C 29 073 €18.81

C 29 075 €7.35

C 29 076 €10.50

C 29 021a

C 29 004 €3.00

C 29 079

A 22 022 €9.06

C 29 082 €4.20

A 29 028 €15.23

B 29 023

Left-hand-drive

C 29 088 €280.50

Right-hand-drive

C 29 089

C 29 094 €23.00

C 29 099 €158.51

C 29 095 €30.47

Left-hand-drive

C 29 102 €11.09

C 29 106 €12.00

Left-hand-drive

C 29 116

Left-hand-drive
